Features and Benefits
・Variety of models made with stainless steel.
・Wide selection available of both 2 pole and 4 pole models.
・As it is made of stainless steel, chemical solutions can be used.
・Back pull-out structure enables disassembly and inspection without removal of suction and discharge piping.
・Expulsion valve is located in the centre of the casing, along with support legs, reinforcing the piping load structure.
Specifications
|
Handling liquid
|
liquid electrolyte | Clear water, oil, chemical liquid |
| temperature | 0 to 100 ℃ | |
| viscosity | 10mPa · s {cP} below | |
| density | 0.7 to 1.0kg / ℓ | |
| Maximum allowable working pressure | 0.98MPa | |
|
structure
|
Impeller | Closed |
| Shaft seal | grand packing, mechanical seal | |
| Bearing | sealed ball bearings, ball bearings (oil bath) | |
|
material
|
Casing | SCS13 |
| Impeller | SCS13 | |
| Main shaft | SUS304 | |
| Flange | JIS10K | |
